Colifts manual chain pully block

Categories: ,

Description

The Colifts Manual Chain Pully Block is engineered for smooth and secure material handling in industrial, construction, and warehouse environments. Designed for long-lasting performance, this manual chain pully block is available in VD and HSC models with capacities ranging from 1 ton to 10 ton, catering to a wide array of lifting needs. Whether you’re lifting small loads or handling large machinery, the Colifts manual chain pully block offers reliability, safety, and ease of use.

📈 Key Features of Colifts Manual Chain Pully Block

  • ⚙️ Precision gearing mechanism ensures smooth lifting

  • 🔩 High-tensile alloy steel load chains for durability

  • 🔒 Mechanical load brake system for added safety

  • 🔄 360° rotating hand wheel for flexible operation

  • 🧰 Low maintenance design for reduced downtime

    🔧 Technical Specifications – Manual Chain Pully Block (Colifts VD & HSC Models)

    Parameter VD Model HSC Model
    Capacity Options 1 Ton, 2 Ton, 3 Ton, 5 Ton, 10 Ton 1 Ton, 2 Ton, 3 Ton,5 Ton
    Load Chain Thickness 6mm, 8mm, 10mm 6mm, 7mm, 9mm
    Chain Length Options 3 Meter, 6 Meter 3 Meter, 6 Meter
    Hand Chain Thickness 4.5mm 4mm
    Number of Falls Single, Double Double, Four
    Operation Manual Manual
    Body Design Compact, Rugged Reinforced Steel Casing
    Application Use Workshop, Warehouse, Factory Shipyard, Industrial Plants

    📦 Available Capacities in Colifts Manual Chain Pully Block Series

    Model Capacity Chain Fall Type Load Chain Thickness Chain Length
    VD 1 Ton Single Fall 6mm 3mtr / 6mtr
    VD 2 Ton Single Fall 8mm 3mtr / 6mtr
    VD 3 Ton Single Fall 10mm 3mtr / 6mtr
    VD 5 Ton Double Fall 10mm 3mtr / 6mtr
    VD 10 Ton Four Fall 10mm 3mtr / 6mtr
    HSC 1 Ton Single Fall 6mm 3mtr / 6mtr
    HSC 2 Ton Double Fall 6mm 3mtr / 6mtr
    HSC 3 Ton Double Fall 7mm 3mtr / 6mtr
    HSC 5 Ton Double Fall 9mm 3mtr / 6mtr

    ✅ Why Choose Colifts Manual Chain Pully Block?

    • Heavy-duty construction for industrial-grade applications

    • Corrosion-resistant body and chains

    • Smooth manual operation with minimum effort

    • Dual and multiple fall options for higher load capacity

    • Ideal for factories, warehouses, shipyards, and workshops

    🛠️ Applications of Manual Chain Pully Block

    • Ideal for lifting engines, machines, and heavy tools

    • Suitable for maintenance tasks and material shifting

    • Commonly used in factories, workshops, garages, and construction sites
