Colifts electric winch 1ton 100 mtr ( three phase )
Colifts electric winch 1ton 100 mtr ( three phase ) - Image 2
Colifts electric winch 1ton 100 mtr ( three phase ) - Image 3
Colifts electric winch 1ton 100 mtr ( three phase ) - Image 4
Colifts electric winch 1ton 100 mtr ( three phase ) - Image 5

Colifts electric winch 1ton 100 mtr ( three phase )

add to cart enquiry
Categories: ,

Description

The Colifts Electric Winch Three Phase with control box  is a high-capacity, industrial-grade winch engineered for lifting, pulling, and hoisting heavy loads up to 1 ton. Powered by a robust 3 HP copper-wound motor, this electric winch three phase model is built for maximum efficiency, reliability, and durability in tough working conditions.

📋 Technical Specifications – Electric Winch 1Ton 60Mtr



Specification Details
Brand Colifts
Product Name Electric Winch 1Ton 100Mtr
Lifting Capacity 1000 kg (1 Ton)
Motor Power 5.3 HP / 3.9 kW
Voltage 440V AC, 3 Phase
Wire Rope Length 100 Meters
Wire Rope Diameter 11mm
Speed 15–20 meters/min (depending on load)
Net Weight Approx. 90-135 kg
Frame Material Heavy-Duty Steel
Winding copper winding
Applications Construction, Warehousing, Marine, Workshops

🔧 Key Features of Colifts Electric Winch 1Ton 100Mtr

  • High Load Capacity: Supports up to 1 ton (1000 kg) of load with ease.

  • Long Wire Rope: Comes with 100 meters of durable, 11mm steel wire rope.

  • Powerful Motor: 3 HP 3-phase copper-wound motor for high torque and efficiency.

  • Compact & Rugged Design: Built for tough industrial conditions.

  • User-Friendly: Easy installation, operation, and maintenance.

  • Enhanced Safety: Equipped with thermal protection and braking system.

  • ⚙️ Why Choose Colifts Electric Winch 1Ton100Mtr?

    • ✅ Heavy-Duty Performance – Built to lift up to 1 ton over 100 meters of vertical height.

    • ✅ Safe & Reliable – Enhanced safety features for smooth and controlled operations.

    • ✅ Versatile Use Cases – Perfect for construction sites, workshops, warehouses, and more.

    • ✅ High-Speed Lifting – Capable of reaching 15–20 m/min to boost productivity.

    • ✅ Durable Build – Industrial-grade motor and gear system designed for long-term use.

      📦 What’s in the Box

      • ✅ Colifts Electric Winch 1Ton100Mtr unit

      • ✅ 100m heavy-duty steel wire rope (11mm)

      • ✅ Dual hooks (top and bottom)

      • ✅ Remote control system

      • ✅ Installation manual

        🔑 Applications of Electric Winch 1Ton100Mtr

        • 🏗️ Construction material lifting

        • 🏬 Warehouse cargo handling

        • 🛠️ Workshop mechanical support

        • ⚓ Dockyard and shipyard hoisting operations

        • 🏞️ Rural and remote area lifting needs
