Colifts electric winch without control box
Description
Introducing Colifts’ premium electric winch line – the ultimate solution for heavy-duty lifting and pulling tasks. Engineered with advanced 3-phase KCD technology, these electric winches deliver unmatched power, durability, and precision for industrial applications
🔧 Key Features
-
Robust Construction: Built to withstand harsh environments, offering long service life
-
High-Efficiency Motor: 3‑phase induction motor delivers smooth operation with minimal maintenance
-
Two Capacity Ranges:
-
500–1000 kg: Compact yet powerful
-
750–1500 kg: Ideal for more demanding lifting
-
-
Wire Rope Options:
-
8 mm thickness, 60 m length – for medium-duty tasks
-
11 mm thickness, 100 m length – for heavy-duty operations
-
-
Motor Power Choices:
-
3.5 hp – energy-efficient for lighter loads
-
5.3 hp – maximum power for heavy-duty applications
-
-
Safety & Control: Integrated braking system and IP-rated housing for safe continuous use
-
Ease of Maintenance: Modular design provides easy access to components for servicing
📊 Technical Specifications & Options
Parameter Option A Option B Capacity (kg) 500–1000 750–1500 Wire Thickness (mm) 8 mm 11 mm Wire Length (m) 60 m 100 m Motor Power (hp) 3.5 hp 5.3 hp Power Supply 3‑phase 380 V AC 3‑phase 380 V AC Control Type Pendant or remote control Pendant or remote control Brake System Electromagnetic brake Electromagnetic brake Duty Cycle 30 % 30 % Operating Temperature –10 °C to +45 °C –10 °C to +45 °C IP Rating IP54 IP54 🛠️ Model Summary
Model
Capacity (kg)
Wire (mm/m)
Motor (hp)
Best For
KCD‑EW‑500‑1000‑8‑60‑3.5
500–1000
8 / 60 m
3.5
Medium-duty lifting with compact footprint
KCD‑EW‑500‑1000‑11‑100‑3.5
500–1000
11 / 100 m
3.5
Extended, heavier pulls within capacity
KCD‑EW‑750‑1500‑8‑60‑5.3
750–1500
8 / 60 m
5.3
Medium to heavy duty, tighter spaces
KCD‑EW‑750‑1500‑11‑100‑5.3
750–1500
11 / 100 m
5.3
High-capacity, long-reach applications
🌟 Why Choose Colifts 3‑Phase KCD Electric Winch?
-
Optimized Power-to-Weight Ratio
The dual capacity ranges ensure you get the right electric winch for your load, maximizing efficiency and minimizing energy consumption. -
Tailored Wire Rope & Length
Select 8 mm x 60 m for lighter, frequent tasks or 11 mm x 100 m for extended, heavier operations—either way, your electric winch is ready when you are. -
Adjustable Motor Power
Choose the 3.5 hp model for cost-effective performance, or go with 5.3 hp for maximum lifting capacity—customize your electric winch to match your workload. -
Enhanced Safety & Rugged Design
All Colifts electric winches feature a fail-safe braking system and IP54 protection, ensuring reliable, safe use in dusty or moist industrial environments. -
Easy Maintenance & Longevity
With its modular design, routine maintenance is quick and hassle-free. Combined with Colifts’ quality engineering, your electric winch becomes a long-term investment.
-
